Over 5 years ago Vincent Driessen shared with us his well established git workflow. It’s very robust and simple (when you wrap your head around it). It almost perfectly fits into agile methodologies. In one of my past projects it was easy to drop in along with migrating from svn to git, and include it to existing Continuous Integration system. And everyone was happy. How about more recent one? Happily not so easy. That’s good i like challenges.
What’s wrong?
Over last 6 months i wanted to adopt it to one of projects in my job (and migrate from filthy svn to git). Of course it’s not so easy because of internal political reasons, policies, produces and tons of documents that has to be signed by millions of people. Hopefully i received information that this can be possible in Q3 or Q4 of 2015’s. So let’s roll up sleeves and prepare some flow charts and graphs.
Current repository situation
If repository has not received any thought beforehand and was managed in free-style way there is no other possibility that it is/was mess. When i heard the story i was amazed. Long story short. At the beginning everything was kept in root
folder. Then src
folder appeared. After some time some real structure came into being with folders like trunk
or branches
and other. Each release is a new branch which is left alone even if new release is published. Each production bugfix is implemented in trunk
and current release branch
.
Deployment flow
At the end of the day internal policies (which i always rant about) became an ally. Hopefully deployment process is well managed and streamlined. I like that there are separate stages for both SAT and UAT. That gives us, developers, after completing scheduled User Stories time to go through Technical Chances. Sadly the client is more interested in new features that technical and internal improvements but who can blame hit for this? So here is release stages breakdown and deployment flow. As you can see each stage has own isolated environment.
Adopting git-flow
Adjusting standard release workflow was not that big issue. As meeting went along i had to be agile and make some slight changes to well known nvie’s workflow. As you can see on current workflow i had to split release-*
branch in two.
When new release cycle is started development code is freezed and no new features are added and SAT cycle begins. New branch sat-*
is created with develop
as a base and deployed to it’s own env. When all found bugs are fixed and verified on development
env new SAT iteration begins along with deployment and retesting on SAT env.
When no new bugs were found UAT cycle begins. Old sat-*
branch is changed to uat-*
and deployed on it’s own env. If any bug is found it have to be fixed and deployed as soon as possible. If all bugs are fixed and all fine and dandy sat-*
branch is merged to develop
to include all bugfixes and also it’s merged master
and deployed to production.
If critical bug is found on production new branch hotfix-*
is created with master
as a base and deployed on it’s own env. If it’s fixed and hotix-*
is changed to uat-*
and UAT cycle begins. If it’s all ok hotfix-*
is merged back to master
and deployed to production. It’s also merged to develop
.
Summary
Changes made are minor and right now obvious. But back then i gave it fair amount of thought to do it in cleaver way. Benefits from migration to this approach and git are significant to me. For example better changes isolation, repository performance boost, ability to manipulate commit history before push them to server, less hassle for CI configuration for each release.
I hope this approach will be accepted and possibly spread among other projects. Also i found that solving this problem and preparing myself to explain changes proposed by me gave me much satisfaction. Maybe this is the point to think again about my career path as a software developer :)
Fun facts
I did PoC for myself that repository can be migrated. The answer is yes. But.
It took about 4 hours to convert svn into git repository. I did wrong the configuration because folder with branches is named branches
instead of branch
so i migrated only half of repo.
When i fixed it (i don’t know exactly how much time it took to fix it along with test fetches) i managed to migrate whole repo in about 9 hours (over 8k commits). I wonder if it’s a network configuration issue or just it takes so much time for every larger svn repo or this particular svn server.
Sadly i didn’t stored any statistics about previous migration mentioned at the very beginning. It would be interesting to compare
